USA Lab H1-5 5L Full Bore Short Path Distillation Turnkey Kit
The USA Labs H1-5 5L Full Bore Short Path Distillation Kit is specially designed head to allow for excellent distillation at a great value. Each glassware kit comes with a USA Lab -30°C to 150°C Heater Chiller and a USA Lab UVP-11 2-stage 11 CFM Vacuum Pump. This kit is designed for high production and consistent results. Don't spend all your money on overpriced distillation kits. Get started right away at a fraction of the cost!
- Model Option: W/ Insulating Top - 300°C 1200RPM | 220-240V 60Hz 15A 800W (5LMANTLE)
- SKU: C-SD5L-H1TK-1
-
Overview
USA Lab H1-5 5L W/ Insulating Top – 300°C 1200RPM | 220-240V 60Hz 15A 800W (5LMANTLE)
The USA Lab H1-2 2L 5L Full Bore Short Path Distillation Kit is made with high quality borosilicate Glass and a wide 45/50 head to allow for excellent distillation, high production, and consistent results. This distillation kit comes with a large 45/50 distillation head, a 34/45 vacuum take-off adapter to allow for easy switching of receiving flasks, two 24/40 cold traps for large amounts of condensing, and full-bore attachments to allow for high pulling vacuum. Choose the best quality at the best value with this lattice supported high quality glass distillation kit.
- Flask Sizes: 2L / 34/45 Main | 24/40 Side
- Head Joint Size: 34/45 Bottom | 24/40 Top | 34/45 Side
- Isolation Adapter Joint Sizes: 34/45 Inlet | 24/40 Outlet | 24/40 Bottom Discharge
- Left Cold Trap Joint Sizes: Male 24/40
- Right Cold Trap Joint Sizes: Female 24/40
- Optimal Capacity: 400-1000mL
- Batch Time: 4-8 Hours
- Main Body Flow Rate: 100-400 grams/hour
- 2LMANTLE Mantle Power: 220-240V 50/60Hz 15A
- USA-HM-5L Mantle Power: 110-120V 50/60Hz 15A
- Heater Chiller Power: 110-120V 50/60Hz 15A
- Vacuum Pump Power: 110-120V 50/60Hz 15A
- Warranty: 1 Year
| SPECIFICATIONS | ||
|---|---|---|
| Model | C-SD5L-H1TK | |
| Flask Size | 5L / 5000ML | |
| Flask Joint Sizes | 45/50 Main | 24/40 Side | |
| Distillation Head Joint Sizes | 45/50 Bottom | 24/40 Top | 34/45 Side | |
| Isolation Adapter Joint Sizes | 34/45 Inlet | 24/40 Outlet | 24/40 Bottom Discharge | |
| Left Cold Trap Joint Sizes | 24/40 | |
| Right Cold Trap Joint Sizes | 24/40 | |
| Optimal Capacity | 800-3000mL | |
| Batch Time | 4-8 Hours | |
| Main Body Flow Rate | 300-700 grams/hour | |
| Footprint | 80x24x40(inch) Including Pump / Chiller | |
| Heating Mantle Power 5LMANTLE | 220-240V 50/60Hz 15A | |
| Heating Mantle Power USA-HM-5L | 110-120V 50/60Hz 15A | |
| Heater Chiller Requirements | 110-120V 50/60Hz 15A | |
| Vacuum Pump Requirements | 110-120V 50/60Hz 15A | |
| Warranty | 1 Year (Pump is a 2 year warranty) | |
| PACKING LIST | ||
|---|---|---|
| Model | Quantity | |
| 5L Mantle (Options) | 1 | |
| USA Lab 11CFM UVP-11 | 1 | |
| USA Lab USA-RHC-7L -20 to 150C Heater Chiller | 1 | |
| DigiVac Bullseye Vacuum Gauge | 1 | |
| Digital K-type Thermometer w/ Probe | 1 | |
| 5L Thermal Shield USA Lab (Only for SKU:5LMANTLE) | 1 | |
| Apiezon PFPE 501 Vacuum Grease 100g | 1 | |
| 5L RBF – 2 neck 24/40 and 45/50 Center | 1 | |
| 5L 45/50 H1-5 Distillation Head | 1 | |
| 500ML RBF – 1 Neck 24/40 | 2 | |
| 1000ML RBF – 1 Neck 24/40 | 1 | |
| 34/45 Isolation Adapter | 1 | |
| 24/40 Male Cold Trap | 1 | |
| 24/40 female Cold Trap | 1 | |
| Cold Trap Lid | 2 | |
| S35/20 500ml RBF | 2 | |
| 5L Flask Thermowell 24/40 | 1 | |
| 5L Head Thermowell 24/40 | 1 | |
| GL-18 Connection | 4 | |
| 45/50 Keck Clamp | 1 | |
| 34/45 Keck Clamp | 1 | |
| 24/40 Keck Clamp | 4 | |
| Red Large Clamp Retort 3 Prong | 4 | |
| Chain Clamp for Lab Stand | 2 | |
| Stainless Steel S35 Pinch Clamp | 2 | |
| 4″ Diameter Extension Support Ring | 2 | |
| Boss Head Clamp | 18 | |
| Small Cork Stand | 2 | |
| Medium Cork Stand | 1 | |
| 6″x8″ Lab Stand | 4 | |
| 8″x8″ Lab Jack | 1 | |
| 48″ SS Rod | 3 | |
| KF25 to 24/40 PTFE Adapter | 1 | |
| KF-25 to KF-25 x 1/8″ FNPT Adapter | 1 | |
| KF25 Bellow Hose 24″ | 1 | |
| KF25 3-Way Tee | 1 | |
| KF25 Pressure Release Valve | 1 | |
| KF25 Right Angle Valve | 1 | |
| KF25 Wing Nut Clamp | 4 | |
| KF25 Vacuum Pump Centering Ring | 4 | |
| Silicone Hosing 3/8″ | 10ft | |
| Mantle Manual | 1 | |
| Pump Manual | 1 | |
| Heater Chiller Manual | 1 | |
